# checkbox

组件类型：UniCheckboxElement

多选项。在1组check-group中可选择多个

# 兼容性

Web	微信小程序	Android	iOS	HarmonyOS	HarmonyOS(Vapor)
4.0	4.41	3.9	4.11	4.61	5.0

# 属性

名称

类型

默认值

兼容性

描述

disabled

boolean

false

是否禁用

value

string

表单的控件名称，作为键值对的一部分与表单(form组件)一同提交

checked

boolean

false

当前是否选中，可用来设置默认选中

~~color~~

string(string.ColorString)

"#007aff"

checkbox的颜色 (使用foreColor替代)

backgroundColor

string(string.ColorString)

"#ffffff"

checkbox默认的背景颜色

borderColor

string(string.ColorString)

"#d1d1d1"

checkbox默认的边框颜色

activeBackgroundColor

string(string.ColorString)

"#ffffff"

checkbox选中时的背景颜色

activeBorderColor

string(string.ColorString)

"#d1d1d1"

checkbox选中时的边框颜色

~~iconColor~~

string(string.ColorString)

"#007aff"

checkbox的图标颜色，优先级大于color属性 (使用foreColor替代)

foreColor

string(string.ColorString)

"#007aff"

checkbox的图标颜色，优先级大于color属性

icon-class

string.ClassString

复选框选中图标的类名

checkbox-class

string.ClassString

复选框未选中的类名

checkbox-active-class

string.ClassString

复选框选中的类名

# 示例

示例为hello uni-app x alpha分支，与最新HBuilderX Alpha版同步。与最新正式版同步的master分支示例另见

示例

<script setup lang="uts">
  type ItemType = {
    value: string
    name: string
    checked: boolean
  }

  type DataType = {
    items: ItemType[];
    testEvent: boolean;
    text: string;
    wrapText: string;
    value: string[];
    disabled: boolean;
    checked: boolean;
    color: string;
    iconColor: string;
    foreColor: string;
    checked_boolean: boolean;
    disabled_boolean: boolean;
    color_input: string;
    backgroundColor_input: string;
    borderColor_input: string;
    activeBackgroundColor_input: string;
    activeBorderColor_input: string;
    iconColor_input: string;
    foreColor_input: string;
  }
  // 使用reactive避免ref数据在自动化测试中无法访问
  const data = reactive({
    items: [
      {
        value: 'CHN',
        name: '中国',
        checked: true,
      },
      {
        value: 'USA',
        name: '美国',
        checked: false,
      },
      {
        value: 'BRA',
        name: '巴西',
        checked: false,
      },
      {
        value: 'JPN',
        name: '日本',
        checked: false,
      },
      {
        value: 'ENG',
        name: '英国',
        checked: false,
      },
      {
        value: 'FRA',
        name: '法国',
        checked: false,
      },
    ],
    testEvent: false,
    text: '未选中',
    wrapText: 'uni-app x，终极跨平台方案\nuts，大一统语言',
    value: [],
    disabled: true,
    checked: true,
    color: '#007aff',
    iconColor: '#211cfe',
    foreColor: '#ff0000',
    // 组件属性 autotest
    checked_boolean: false,
    disabled_boolean: false,
    color_input: "#007aff",
    backgroundColor_input: "#ffffff",
    borderColor_input: "#d1d1d1",
    activeBackgroundColor_input: "#ffffff",
    activeBorderColor_input: "#d1d1d1",
    iconColor_input: "#007aff",
    foreColor_input: '#ff0000'
  } as DataType)

  const checkboxChange = (e: UniCheckboxGroupChangeEvent) => {
    // 自动化测试
    if ((e.target?.tagName ?? '') == 'CHECKBOX-GROUP' && e.type === 'change') {
      data.testEvent = true
    }

    const selectedNames: string[] = []
    data.items.forEach((item) => {
      if (e.detail.value.includes(item.value)) {
        selectedNames.push(item.name)
      }
    })
    uni.showToast({
      icon: 'none',
      title: '当前选中:' + selectedNames.join(','),
    })
  }

  const testChange = (e: UniCheckboxGroupChangeEvent) => {
    data.value = e.detail.value
  }

  const checkbox_click = () => {
    console.log("组件被点击时触发")
  }

  const checkbox_touchstart = () => {
    console.log("手指触摸动作开始")
  }

  const checkbox_touchmove = () => {
    console.log("手指触摸后移动")
  }

  const checkbox_touchcancel = () => {
    console.log("手指触摸动作被打断，如来电提醒，弹窗")
  }

  const checkbox_touchend = () => {
    console.log("手指触摸动作结束")
  }

  const checkbox_tap = () => {
    console.log("手指触摸后马上离开")
  }

  const checkbox_longpress = () => {
    console.log("如果一个组件被绑定了 longpress 事件，那么当用户长按这个组件时，该事件将会被触发。")
  }

  const change_checked_boolean = (checked: boolean) => {
    data.checked_boolean = checked
  }

  const change_disabled_boolean = (checked: boolean) => {
    data.disabled_boolean = checked
  }

  const confirm_color_input = (value: string) => {
    data.color_input = value
  }

  const confirm_backgroundColor_input = (value: string) => {
    data.backgroundColor_input = value
  }

  const confirm_borderColor_input = (value: string) => {
    data.borderColor_input = value
  }

  const confirm_activeBackgroundColor_input = (value: string) => {
    data.activeBackgroundColor_input = value
  }

  const confirm_activeBorderColor_input = (value: string) => {
    data.activeBorderColor_input = value
  }

  const confirm_iconColor_input = (value: string) => {
    data.iconColor_input = value
  }

  const confirm_foreColor_input = (value: string) => {
    data.foreColor_input = value
  }

  defineExpose({
    data
  })
</script>

<template>
  <view class="main">
    <checkbox :disabled="data.disabled_boolean" :checked="data.checked_boolean" :color="data.color_input"
      :iconColor="data.iconColor_input" :foreColor="data.foreColor_input" :backgroundColor="data.backgroundColor_input"
      :borderColor="data.borderColor_input" :activeBackgroundColor="data.activeBackgroundColor_input"
      :activeBorderColor="data.activeBorderColor_input" @click="checkbox_click" @touchstart="checkbox_touchstart"
      @touchmove="checkbox_touchmove" @touchcancel="checkbox_touchcancel" @touchend="checkbox_touchend"
      @tap="checkbox_tap" @longpress="checkbox_longpress"><text>uni-app-x</text></checkbox>
  </view>

  <scroll-view style="flex: 1">
    <view class="content">
      <page-head title="组件属性"></page-head>
      <boolean-data :defaultValue="false" title="当前是否选中，可用来设置默认选中" @change="change_checked_boolean"></boolean-data>
      <boolean-data :defaultValue="false" title="是否禁用" @change="change_disabled_boolean"></boolean-data>
    </view>

    <view>
      <page-head title="默认及使用"></page-head>
      <view class="uni-padding-wrap uni-common-mt">
        <view class="uni-title uni-common-mt">
          <text class="uni-title-text"> 默认样式 </text>
        </view>
        <view>
          <checkbox-group class="uni-flex uni-row checkbox-group" @change="testChange" style="flex-wrap: wrap">
            <checkbox value="cb" :checked="data.checked" :color="data.color" :iconColor="data.iconColor"
              :foreColor="data.foreColor" style="margin-right: 15px" class="checkbox cb">选中
            </checkbox>
            <checkbox value="cb1" style="margin-right: 15px" class="checkbox cb1">{{ data.text }}</checkbox>
            <checkbox value="cb2" :disabled="data.disabled" class="checkbox cb2">禁用</checkbox>
            <checkbox value="cb3" style="margin-top: 10px" class="checkbox cb3">
              {{ data.wrapText }}
            </checkbox>
          </checkbox-group>
        </view>
        <view class="uni-title uni-common-mt">
          <text class="uni-title-text"> 不同颜色和尺寸的checkbox </text>
        </view>
        <view>
          <checkbox-group class="uni-flex uni-row checkbox-group">
            <!-- #ifndef VUE3-VAPOR -->
            <checkbox value="cb1" :checked="true" color="#FFCC33" style="transform: scale(0.7); margin-right: 15px"
              class="checkbox">选中
            </checkbox>
            <checkbox value="cb" color="#FFCC33" style="transform: scale(0.7)" class="checkbox">未选中</checkbox>
            <!-- #endif -->

            <!-- #ifdef VUE3-VAPOR -->
            <checkbox value="cb1" :checked="true" icon-class="custom-icon"
              style="transform: scale(0.7); margin-right: 15px" class="checkbox">选中
            </checkbox>
            <checkbox value="cb" icon-class="custom-icon" style="transform: scale(0.7)" class="checkbox">未选中</checkbox>
            <!-- #endif -->
          </checkbox-group>
        </view>
        <view class="uni-title uni-common-mt">
          <text class="uni-title-text"> 两端对齐样式测试 </text>
        </view>
        <view>
          <checkbox-group class="uni-flex uni-row checkbox-group">
            <checkbox class="justify-test">justify-content样式测试</checkbox>
          </checkbox-group>
        </view>
      </view>

      <!-- #ifdef VUE3-VAPOR -->
      <view class="uni-padding-wrap">
        <view class="uni-title uni-common-mt">
          <text class="uni-title-text"> 自定义 checkbox </text>
        </view>
        <checkbox-group class="uni-flex uni-row checkbox-group">
          <checkbox checkbox-class="custom-checkbox" id="checkbox-vapor"> 自定义 checkbox </checkbox>
        </checkbox-group>
      </view>
      <!-- #endif -->

      <view class="uni-padding-wrap">
        <view class="uni-title uni-common-mt">
          <text class="uni-title-text"> 推荐展示样式 </text>
        </view>
      </view>
      <view class="uni-list uni-common-pl">
        <checkbox-group @change="checkboxChange" class="checkbox-group" id="trigger-change">
          <checkbox class="uni-list-cell uni-list-cell-pd checkbox" v-for="(item, index) in data.items"
            :key="item.value" :value="item.value" :checked="item.checked" :class="[
              index < data.items.length - 1 ? 'uni-list-cell-line' : '',
              'checkbox-item-' + index,
            ]">
            {{ item.name }}
          </checkbox>
        </checkbox-group>
      </view>
    </view>

    <!-- #ifndef VUE3-VAPOR -->
    <view>
      <input-data defaultValue="#007aff" title="checkbox的颜色" type="text" @confirm="confirm_color_input"></input-data>
      <input-data defaultValue="#ffffff" title="checkbox默认的背景颜色" type="text"
        @confirm="confirm_backgroundColor_input"></input-data>
      <input-data defaultValue="#d1d1d1" title="checkbox默认的边框颜色" type="text"
        @confirm="confirm_borderColor_input"></input-data>
      <input-data defaultValue="#ffffff" title="checkbox选中时的背景颜色" type="text"
        @confirm="confirm_activeBackgroundColor_input"></input-data>
      <input-data defaultValue="#d1d1d1" title="checkbox选中时的边框颜色" type="text"
        @confirm="confirm_activeBorderColor_input"></input-data>
      <input-data defaultValue="#007aff" title="iconColor: checkbox的图标颜色，优先级大于color属性" type="text"
        @confirm="confirm_iconColor_input"></input-data>
      <input-data defaultValue="#ff0000" title="foreColor: checkbox的图标颜色，优先级大于color属性" type="text"
        @confirm="confirm_foreColor_input"></input-data>
    </view>
    <!-- #endif -->

    <navigator class="uni-common-mb" url="/pages/template/checkbox-200/checkbox-200">
      <button class="uni-common-mt">组件性能测试</button>
    </navigator>
  </scroll-view>
</template>

<style>
  .main {
    max-height: 250px;
    padding: 5px 0;
    border-bottom: 1px solid rgba(0, 0, 0, 0.06);
    flex-direction: row;
    justify-content: center;
  }

  .uni-list-cell {
    justify-content: flex-start;
  }

  .justify-test {
    width: 100%;
    justify-content: space-between;
  }

  /* #ifdef VUE3-VAPOR */
  .custom-icon {
    color: #FFCC33;
  }

  .custom-checkbox {
    background-color: #e1e1e180;
    border-color: #ffffff;
  }
  /* #endif */
</style>
